Chromebook to Jessiebook
Replace ChromeOS permanently with Debian on the Acer C720 Chromebook.
Running a full-featured Linux on this little laptop is a delight: lightweight, several hours battery life, inexpensive, and snappy performance. I started with Debian, followed by Lubuntu, Arch, Ubuntu, and have now returned to the latest Debian
This device is available in a few different configurations. Mine is the non-touchscreen model
C720-2848 with (non-expandable) 2GB RAM and a (user-replaceable) 16GB SSD.
Create a recovery image of Chrome OS (my C720 is model
PEPPY C6A-N3C-A7O) to enable restoring the Chromebook to its default configuration. 1 This will require a spare USB stick of 2GB or better:
- Log into the Chromebook and let it auto update, as there sometimes are firmware updates... Check the updating status in the browser at
- Insert the USB stick, enter
chrome://imageburnerand follow the directions to generate a recovery image
Prepare install media
Download the 64-bit minimal installer and flash the image to a USB stick. Using the minimal console installer (requires network connection) downloads all the latest packages during setup.
SeaBIOS in combination with Coreboot provides an open-source legacy BIOS that enables access to the MBR and the ability to install an alternative OS on the Chromebook. All this good stuff involves jumping through a few simple hoops and not trembling in fear at the "scary white screen" that pops up at power up stating that the boot loader detects something is very very wrong with the Chromebook and helpfully suggests pressing the spacebar to begin recovery. Do not press the spacebar or the Debian installation will be wiped from disk!
There are 2 different methods for configuring SeaBIOS in preparation for installing Debian. First method uses a few simple commands in the Chrome OS shell to place the Chromebook into developer mode and allow booting the USB install media and replacing Chrome OS with Debian. The drawback is that scary screen appears at every boot and you must press
CTRL+L to boot to legacy-mode and onward to GRUB and Debian (and ignore the helpful prompt to press spacebar and inadvertently begin the adventure of wiping clean the SSD).
Second method involves setting new flags for the write-protected Google Binary Block (GBB) in the device firmware. Delay at the boot screen can be reduced to a one second timeout and the legacy-mode BIOS set as the system default (no key combo required). Pressing the spacebar is disabled from doing any harm to Debian (the Chromebook just beeps). The drawback is that it involves the (very simple) removal of the device's bottom cover and the temporary removal of the write-protect screw from the motherboard to permit flashing new flags to the GBB. This may void the Chromebook's warranty (one of the case screws lies underneath a sticker declaring the warranty void if disturbed).
Experimenting with alternate OS installs on the Chromebook I first employed the developer mode method followed by the write-protect screw removal. I prefer configuring the device to default to legacy-mode BIOS but I have employed both methods successfully and describe their respective steps below.
Write-Protect Screw Method
Disconnect power. Turn the Chromebook over facing bottom up and remove the 13 screws (not missing the one hidden under the warranty sticker). Gently pry the case off starting with the seam where the display connects to device. It comes away pretty easy.
This is what you see ...
Image: 2 The battery lock screw is #6 and the write-protect screw is #7.
WARNING! This will wipe out whatever is installed on the SSD:
- Remove the write-protect screw
- Close back cover using only the battery lock screw to hold in place
- Re-connect power, boot Chromebook and wait until it displays ...
Chrome OS is missing or damaged. Please insert a recovery USB stick or SD card.
- Insert USB recovery media prepared in Step 0 and it will proceed to restore Chrome OS and reboot
- At default Chrome OS "Welcome!" screen open a terminal
- Login as
chronos(no password), then enter
sudo sufor superuser access
Set new GBB flags 3 using the
set_gbb_flags.sh script in Chrome OS. Enable short developer mode screen (1 second timeout) followed by default legacy mode boot by using these flags ...
GBB_FLAG_DEV_SCREEN_SHORT_DELAY 0×00000001 GBB_FLAG_FORCE_DEV_SWITCH_ON 0×00000008 GBB_FLAG_FORCE_DEV_BOOT_LEGACY 0×00000080 GBB_FLAG_DEFAULT_DEV_BOOT_LEGACY 0×00000400
... which adds up to running in the shell ...
shutdown -h now
... and disconnect the power:
- Remove the bottom cover again and reinstall the write-lock screw to protect the BIOS
- Close cover and reinstall all the case screws
Re-connect power, insert USB stick prepared in Step 1, and power up Chromebook. 4
Alternative: Developer Mode Method
The alternative to removing the write-protect screw above is to place the Chromebook into developer mode 5 using the Chrome OS shell before booting the USB install media:
- With the Chromebook off... Hold down
ESC+F3(Refresh) keys and power on the device
- Invoke Recovery, and at the Recovery screen press
- Device will prompt for confirmation, press
ENTERand the system reboots into developer mode
- Scary white boot screen appears and you need to press
Ctrl+Dto continue boot
Enable the USB Boot and Legacy BIOS modes by opening the shell with
Ctrl+Alt+T and enter
dev_boot_legacy to active ...
sudo crossystem dev_boot_usb=1 sudo crossystem dev_boot_legacy=1
Insert USB stick prepared in Step 1, reboot the Chromebook and press
CTRL+L at the boot screen to enter legacy boot mode. 6
My screenshot tour installing the Debian stable release. I use Debian's minimal network install image to create a console-only base configuration that can be customized for various tasks and alternate desktops.
Debian jessie/stable installs Linux kernel 3.16 with backported support for Chromebook touchpad. Per-session modifications of touchpad settings can be made using
synclient ## display current settings synclient TapButton3=2 ## 3-finger tap = middle-click
Make any desired touchpad settings permanent by creating
sudo mkdir /etc/X11/xorg.conf.d sudo cp /usr/share/X11/xorg.conf.d/50-synaptics.conf /etc/X11/xorg.conf.d/50-c720-touchpad.conf
Modify to adjust timeouts, add tap-mouse actions (2-finger tap = right-click, 3-finger tap = middle-click), and 2-finger scrolling. 7
Section "InputClass" Identifier "touchpad peppy cyapa" MatchIsTouchpad "on" MatchDevicePath "/dev/input/event*" MatchProduct "cyapa" Option "FingerLow" "5" Option "FingerHigh" "5" Option "VertEdgeScroll" "0" Option "VertTwoFingerScroll" "1" Option "HorizTwoFingerScroll" "1" Option "AreaRightEdge" "850" Option "AreaLeftEdge" "50" Option "TapButton1" "1" Option "TapButton2" "3" Option "TapButton3" "2" EndSection
Swappiness parameter controls the preference of the kernel to move processes out of physical memory to the swap partition. Range is 0-100, default is set to 60 and lower values cause the kernel to avoid swapping and higher values prompt more frequent swap use.
Check current swappiness value ...
Reduce SSD writes by setting a low value of
Suspend-and-resume generates a stream of errors ...
ehci-pci 0000:00:1d.0: port 1 resume error -19 ehci-pci 0000:00:1d.0: port 2 resume error -19 usb usb3-port1: over-current condition usb usb3-port1: connect-debounce failed usb usb3-port2: over-current condition usb usb3-port2: connect-debounce failed
... and blocks Jessiebook from executing a proper restart/shutdown.
[ FIX! ] 8 Create
#!/bin/bash case $1/$2 in pre/*) # Unbind ehci for preventing error echo -n "0000:00:1d.0" | tee /sys/bus/pci/drivers/ehci-pci/unbind ;; post/*) # Bind ehci for preventing error echo -n "0000:00:1d.0" | tee /sys/bus/pci/drivers/ehci-pci/bind ;; esac
Make the script executable ...
sudo chmod 755 /lib/systemd/system-sleep/ehci-pci.sh
Configure boot options in
Update GRUB ...
Top row on the keyboard with the shortcut icons (
Volume, etc.) identify in Linux as
F1-F10 keys and the
Search key (in
CapsLk position) acts as
Super (Windows) modifier key.
Create keyboard shortcuts by installing ...
xbindkeys- associate keys to shell commands
xbacklight- set backlight level using RandR
pulseaudio-utils- manage sound with
xvkbd- send characters to another client
sudo apt-get install xbindkeys xbacklight pulseaudio-utils xvkbd
Direction, Brightness, Volume, Page Keys
Enable function keys to modify sound, brightness, and page movements by creating
~/.xbindkeysrc. Discover the keycode for a particular key by running ...
... press the key of interest, and a snippet of code is outputted that can be added to
My own config for the chromebook ...
# Backward/forward "xvkbd -xsendevent -text "\A\[Left]"" F1 "xvkbd -xsendevent -text "\A\[Right]"" F2 # Backlight decrease/increase "xbacklight -dec 10" F6 "xbacklight -inc 10" F7 # Volume mute/decrease/increase # paVolume "paVolume -m" F8 "paVolume -m" XF86AudioMute "paVolume -d" F9 "paVolume -d" XF86AudioLowerVolume "paVolume -u" F10 "paVolume -u" XF86AudioRaiseVolume # Page up/down, home, end "xvkbd -xsendevent -text '\[Page_Up]'" Alt + Up "xvkbd -xsendevent -text '\[Page_Down]'" Alt + Down "xvkbd -xsendevent -text '\[Home]'" Alt + Left "xvkbd -xsendevent -text '\[End]'" Alt + Right
Enable new key shortcuts ...
~/.xinitrc to load configuration at
startx ... 9
if [ -f ~/.xbindkeysrc ]; then xbindkeys fi
Link: .xbindkeysrc and .xinitrc
Power key in upper-right corner ignores any configuration in the window manager and triggers poweroff without delay when pressed (easy to do by accident as its positioned next to
If you want to disable the power key edit
/etc/systemd/logind.conf and set
There are a few settings to modify to improve performance of Chromebook's wireless chipset. 10 Identify the card and parameters ...
lspci | grep -i net 01:00.0 Network controller: Qualcomm Atheros AR9462 Wireless Network Adapter (rev 01) $ modinfo ath9k | grep parm parm: debug:Debugging mask (uint) parm: nohwcrypt:Disable hardware encryption (int) parm: blink:Enable LED blink on activity (int) parm: btcoex_enable:Enable wifi-BT coexistence (int) parm: bt_ant_diversity:Enable WLAN/BT RX antenna diversity (int) parm: ps_enable:Enable WLAN PowerSave (int) parm: use_chanctx:Enable channel context for concurrency (int)
options ath9k bt_ant_diversity=1 ps_enable=0
Confirm the microphone is unmuted in
options snd_hda_intel model=,alc283-dac-wcaps
... and restart (I couldn't get the module to unload). Give it a try ...
arecord -d 5 chr-mic.wav aplay chr-mic.wav
- Specs: output of lshw, lspci, and lsusb
- Arch Linux C720 installation with useful post-install details
- Turn chromebooks into Ubuntu-based code learning machines for kids
Create a Chromebook recovery image.
Image courtesy of Chromium.
Whenever you remove battery power to the Chromebook (like opening up the case) the hardware clock on the motherboard resets to a future year (mine travelled to 2040). Providing a network connection is up during the Debian installation the system should fetch a correct time from a NTP server. Otherwise fix the fallout from an incorrect clock by re-mounting partitions read-only and correct filesystem timestamps using
Switching between developer and normal (non-developer) modes will remove user accounts and their associated information from the Chromebook.
Some HOWTOs talk about adding
